Tuoyuan Katana MKIII(Final Version)

(1 customer review)

899.00$

If you choose handmade saya, the production time at least will be 2 months longer.

——————————————-
<Koshirae>
——————————————-
■Tsuba:Iron
■F&K:White Copper
■Menuki:Brass Blackened
■Seppa:Brass Nickel Plated (Silver)
■Habaki:White Copper
■Tsuka:Handmade Tsuka(Haichi Style)
■Tsuka Samegawa:White Rayskin (Normal Emperor Node)
■Tsuka Ito:Silk Ito From Japan・Black(High Quality Hishigami)
■Mukugi:1
■Kashira&Kurikata Shitodome:White Copper
■Saya:Hron Koiguchi、Kurikata、Kojiri
■Saya Style:黑石目塗り (Oil Lacquer)
■Sageo:Silk Sageo From Japan・Golden Brown
——————————————-
<Blade>
——————————————-
■Nagasa:71CM
■Motohaba:3.2CM
■Motokasane:0.7CM
■Sakihaba:2.4CM
■Sakikasane:0.4CM
■Sori:About 1.5CM
■Tsuka Length:26CM
■Bohi:No Bohi
■Material:Crucible Steel
■Hamon Style:Suguha Style Hamon
■Blade Style:Shinogi Zukuri
■Heat Treatment:  Clay Temper
■With And Without Saya Weight:1230g/997g

Warning:The data is just for reference because the handmade products’s data has error.
——————————————-
<Polishing>
——————————————-
■Polishing:Sashikomi A
——————————————-

*******************************************



Category: Tags: , , ,

Note:

MKI is the earlist version.

MKII made an overall upgrade on the basis of MKI and the price rised from 600USD to 899USD.

2022.11.20 MKIII is the final version, which changed the fittings which have higher quality and some optimization of details.

Introduction to tuoyuan katana:

– The blade is handmade using ancient sword forging methods. Fully handcrafted forging and fully handcrafted polishing.

-The blade is made of the steel improved by ourselves, differentially hardened and clay tempered, water quenched, and the hardness is approximately 56HRC.

– This blade has been tested to cut through everything that gets in its way, such as, it can easily cut through tatami mats. Sori (blade curvature) is specially designed to create leverage to perform the smoothest, cleanest cuts. The fuchi&kashira is cherry blossom theme made by ourselves, which is our best selling fittings.

– The real Hamon pattern is done in the same process as the traditional method. Edge hardening is using special clay to wrap the back of the blade and expose the cutting edge, heating it to a certain temperature and then putting it in water to quench it. This step is very demanding for a craftsman, and if he is not experienced, it will be difficult for him to succeed. Just this process creates out beautiful hamon. A special clay protects the back of the blade, and varying degrees of hardening of the blade causes the blade to bend, resulting in a perfect sori.

– This sword is made with yasurime. And the tsuka is handmade totally according to nakago, whose section is very neat and has no burrs. There is a mekugi on tsuka, the edges are made rounded. the rayskin used by tsuka is large particle rayskin, which is very expensive, and the ito is silk imported from Japan for wrapping. Expert finish on the end knot of the ito, to prevent uneven surfaces and bumps.

Fittings:

The chrysanthemum Tsuba of the sword is made of iron. The Fuchi and Kashira are made of high-quality cupronickel. The copper Habaki is a one piece construction. The tsuba and habaki fit very well with the blade, as you can see in the picture. Two red copper Seppas hold Tsuba in place to provide cushioning power when cutting.
